Product Summary

The BYV26C is a fast soft-recovery controlled avalanche rectifier. This package is hermetically sealed and fatigue free as coefficients of expansion of all used parts arematched. It is the Rugged glass SOD57 package, using a high temperature alloyed construction.

Parametrics

BYV26C absolute maximum ratings: (1)repetitive peak reverse voltage:600V; (2)continuous reverse voltage:600V; (3)average forward current:1A,0.65A; (4)repetitive peak forward current:10A.

Features

BYV26C features: (1)Glass passivated; (2)High maximum operating temperature; (3)Low leakage current; (4)Excellent stability; (5)Guaranteed avalanche energy absorption capability; (6)Available in ammo-pack.

Diagrams

BYV26C PACKAGE OUTLINE

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
BYV26C
BYV26C
Other

Data Sheet
Negotiable
BYV26C-TR
BYV26C-TR
Vishay Semiconductors
Rectifiers 1 Amp 600 Volt 30 Amp IFSM
Data Sheet
0-1: $0.17
1-10: $0.15
10-100: $0.14
100-250: $0.13
BYV26C-TAP
BYV26C-TAP
Vishay Semiconductors
Rectifiers 1 Amp 600 Volt 30 Amp IFSM
Data Sheet
0-1: $0.16
1-10: $0.15
10-100: $0.13
100-250: $0.13
