ADC0838

ADC0838, converter, DIP, National Semiconductor, 15mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.10~1.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.10~1.40

PartNumber:: ADC0838

Brand:: National Semiconductor - NS | Pack: DIP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. bei's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-11-08

From Other Seller

Part Number:ADC0838
US $1.10 - 1.40
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ADC0838 is an 8-bit successive approximation A/D converter with serial I/O and configurable input multiplexers with up to 8 input channels. All errors of the sample-and-hold, incorporated on the ADC0838CCN are accounted for in the analog-to-digital converters accuracy specification.

Parametrics

ADC0838 absolute maximum ratings: (1)Current into V+: 15mA; (2)Supply Voltage, VCC: 6.5V; (3)Voltage Logic Inputs: –7 to VCC +7V; (4)Analog Inputs: –0.3V to VCC +0.3V; (5)Input Current per Pin: ±25mA; (6)Storage Temperature: –65℃ to 150℃; (7)Package Dissipation; (8)at TA = 25℃ (Board Mount): 800mW; (9)Lead Temperature (Soldering 10 sec.): 260℃; (10)Vapor Phase (60 sec.): 215℃; (11)Infrared (15 sec.): 220℃.

Features

ADC0838 features: (1)Conversion time: 6μs; (2)Total unadjusted error: ±1/2LSB or ±1LSB; (3)Sample-and-hold: 375ns acquisition; (4)2, 4 or 8-input multiplexer options; (5)0 to 5V analog input range with single 5V power supply; (6)Operates ratiometrically or with up to 5V voltage reference; (7)No zero or full-scale adjust required; (8)ML2281 capable of digitizing a 5V, 40kHz sine wave; (9)Low power: 12.5mW MAX; (10)Superior pin compatible replacement for ADC0831, ADC0832, ADC0834, and ADC0838; (11)Analog input protection: 25mA (min) per input; (12)Now in 8-Pin SOIC Package (ML2281, ML2282).
