Product Summary

The E28F640J3A120 is an FPGA device of cyclone III series.

Parametrics

E28F640J3A120 absolute maximum ratings: (1)Supply voltage for internal logic, VCCINT: –0.5 to 1.8V; (2)Supply voltage for output buffers, VCCIO: –0.5 to 3.9V; (3)Supply voltage (analog) for phase-locked loop (PLL) regulator, VCCA: –0.5 to 3.75V; (4)Supply voltage (digital) for PLL, VCCD_PLL: –0.5 to 1.8V; (5)DC input voltage, VI: –0.5 to 3.95V.

Features

E28F640J3A120 features: (1)DC output current, per pin, IOUT: -25 to 40mA; (2)Electrostatic discharge voltage using the human body model, VESDHBM: ±2000V max; (3)Electrostatic discharge voltage using the charged device model, VESDCDM: ±500V max; (4)Storage temperature, TSTG: –65 to 150℃; (5)Operating junction temperature, TJ: –40 to 125℃.

Diagrams

E28F640J3A120 block diagram
