Product Summary

The LT1037CN8 is a Low Noise, High Speed Precision Operational Amplifier. Application areas of the LT1037CN8 include Low Noise Signal Processing, Microvolt Accuracy Threshold Detection.

Parametrics

LT1037CN8 absolute maximum ratings: (1)Supply Voltage: ±22V; (2)Input Voltage: Equal to Supply Voltage; (3)Output Short-Circuit Duration: Indefinite; (4)Differential Input Current (Note 8):±25mA; (5)Storage Temperature Range: –65°C to 150°C.

Features

LT1037CN8 features: (1)0.1Hz to 10Hz Noise, 60nVP-P Typical; (2)Guaranteed 7 Million Min Voltage Gain, RL = 2k; (3)Guaranteed 3 Million Min Voltage Gain, RL = 600W; (4)Guaranteed 25mV Max Offset Voltage; (5)Guaranteed 0.6mV/°C Max Drift with Temperature; (6)Guaranteed 11V/ms Min Slew Rate (LT1037).

Diagrams

LT1037CN8 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LT1037CN8
LT1037CN8


IC PREC OP-AMP HI-SPD SNGL 8-DIP

Data Sheet

0-3450: $1.17
LT1037CN8#PBF
LT1037CN8#PBF


IC PREC OP-AMP HI-SPD SNGL 8-DIP

Data Sheet

0-1: $2.18
1-25: $1.45
25-100: $1.17
