Product Summary

The MAX232DRG4 is a Multichannel Driver. The MAX232DRG4 belongs to the family of line drivers/receivers isintended for all EIA/TIA-232E and V.28/V.24 communica-tions interfaces, particularly applications where ±12V is not available.These parts are especially useful in battery-powered systems, since their low-power shutdown mode reduces power dissipation to less than 5μW. The MAX232DRG4 uses no external components and is recommended for applications where printed circuit board space is critical. Applications include Portable Computers, Low-Power Modems, Interface Translation, Battery-Powered RS-232 systems and Multidrop RS-232 Networks.

Parametrics

MAX232DRG4 absolute maximum ratings: (1)Supply Voltage (VCC): -0.3V to +6V; (2)V+ (Note 1): (VCC - 0.3V) to +14V; (3)V- (Note 1): +0.3V to +14V; (4)Input voltages: TIN -0.3V to (VCC - 0.3V), RIN (Except MAX220) ±30V, RIN (MAX220) ±25V, TOUT (Except MAX220) (Note 2) ±15V, TOUT (MAX220) ±13.2V; (5)Output Voltages: TOUT±15V, ROUT -0.3V to (VCC + 0.3V); (6)Driver/Receiver Output Short Circuited to GND: Continuous; (7)Storage Temperature Range: -65℃ to +160℃; (8)Lead Temperature (soldering, 10s) (Note 3): +300℃.

Features

MAX232DRG4 features: (1)For Low-Voltage, Integrated ESD Applications; (2)For Low-Cost Applications.

Diagrams

MAX232DRG4 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
MAX232DRG4
MAX232DRG4
Texas Instruments
RS-232 Interface IC Dual EIA-232 Driver/ Receiver
Data Sheet
0-1750: $0.26
1750-2000: $0.24
2000-2500: $0.24
2500-5000: $0.23
