MP1482DS-LF-Z

monolithic synchronous buck regulator, Monolithic Power System, 2A, 18V, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.20~0.25 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.20~0.25

PartNumber:: MP1482DS-LF-Z

Brand:: Monolithic Power Systems - MPS | Pack: SOP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. bei's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-13

From Other Seller

Part Number:MP1482DS-LF-Z
US $0.20 - 0.25
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MP1482DS-LF-Z is a monolithic synchronous buck regulator. The device integrates two 130mΩ MOSFETs, and provides 2A of continuous load current over a wide input voltage of 4.75V to 18V. Current mode control provides fast transient response and cycle-by-cycle current limit. An adjustable soft-start prevents inrush current at turn-on, and in shutdown mode the supply current drops to 1 μA. The MP1482DS-LF-Z, available in an 8-pin SOIC package, provides a very compact solution with minimal external components.

Parametrics

MP1482DS-LF-Z specifications: (1)Vin (Min): 4.75V; (2)Vin (Max): 18V; (3)lout (Max): 2A; (4)Isw Typ: 3.4A; (5)Iq (Typ): 1.3mA; (6)Vfb: 0.923V; (7)Freq 1: 340kHz.

Features

MP1482DS-LF-Z features: (1)2A Output Current; (2)Wide 4.75V to 18V Operating Input Range; (3)Integrated 130mΩ Power MOSFET Switches; (4)Output Adjustable from 0.923V to 15V; (5)Up to 93% Efficiency; (6)Programmable Soft-Start; (7)Stable with Low ESR Ceramic Output Capacitors; (8)Fixed 340kHz Frequency; (9)Cycle-by-Cycle Over Current Protection; (10)Input Under Voltage Lockout.
