Product Summary

The SST89E58RD2 is a FlashFlex51 MCU. The devices use the 8051 instruction set and are pin-for-pin compatible with standard 8051 microcontroller devices.

Parametrics

SST89E58RD2 absolute maximum ratings: (1)Ambient Temperature Under Bias: -55°C to +125°C; (2)Storage Temperature: -65°C to +150°C; (3)Voltage on EA# Pin to VSS : -0.5V to +14.0V; (4)D.C. Voltage on Any Pin to Ground Potential : -0.5V to VDD+0.5V; (5)Transient Voltage (<20ns) on Any Other Pin to VSS: -1.0V to VDD+1.0V.

Features

SST89E58RD2 features: (1)8-bit 8051-Compatible Microcontroller (MCU) with Embedded SuperFlash Memory; (2)SST89E5xRC Operation; (3)Single Block SuperFlash EEPROM; (4)Full-Duplex, Enhanced UART; (5)Eight Interrupt Sources at 4 Priority Levels.

Diagrams

SST89E58RD2 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
SST89E58RD2
SST89E58RD2

Other


Data Sheet

Negotiable
SST89E58RD2-40-C-NJE
SST89E58RD2-40-C-NJE

Microchip Technology

8-bit Microcontrollers (MCU) 40KB+1KB 40MHz

Data Sheet

Negotiable
SST89E58RD2A-40-C-NJE
SST89E58RD2A-40-C-NJE

Microchip Technology

8-bit Microcontrollers (MCU) 40K (32Kx8K) 40MHz

Data Sheet

0-1: $1.76
1-10: $1.40
10-25: $1.25
25-100: $1.16
SST89E58RD2-40-C-TQJE
SST89E58RD2-40-C-TQJE

Microchip Technology

8-bit Microcontrollers (MCU) 4.5-5.5V FL Flex 8B 8051 Microcontroller

Data Sheet

0-1: $1.74
1-10: $1.59
10-25: $1.42
25-100: $1.32
SST89E58RD2-40-I-NJE
SST89E58RD2-40-I-NJE

Microchip Technology

8-bit Microcontrollers (MCU) 4.5-5.5V FL Flex 8B 8051 Microcontroller

Data Sheet

0-1: $1.52
1-10: $1.40
10-25: $1.25
25-100: $1.16
SST89E58RD2-40-I-TQJE
SST89E58RD2-40-I-TQJE

Microchip Technology

8-bit Microcontrollers (MCU) 4.5-5.5V FL Flex 8B 8051 Microcontroller

Data Sheet

0-1: $1.74
1-10: $1.59
10-25: $1.42
25-100: $1.32
SST89E58RD2A-40-C-TQJE
SST89E58RD2A-40-C-TQJE

Microchip Technology

8-bit Microcontrollers (MCU) 8-Bit 32K+8K Flash 40MHz 3/16-Bit Timer

Data Sheet

0-155: $1.32
SST89E58RD2A-40-I-TQJE-T
SST89E58RD2A-40-I-TQJE-T

Microchip Technology

Flash 4.5V to 5.5V Fl Flex 8-bit

Data Sheet

0-1395: $1.36
1395-1500: $1.36
