Product Summary
The FDP3632 is a n-channel powertrench mosfet. The FDP3632 applications are (1)DC/DC converters and Off-Line UPS; (2)Distributed Power Architectures and VRMs; (3)Primary Switch for 24V and 48V Systems; (4)High Voltage Synchronous Rectifier; (5)Direct Injection / Diesel Injection Systems; (6)42V Automotive Load Control; (7)Electronic Valve Train Systems.
Parametrics
FDP3632 absolute maximum ratings: (1)VDSS Drain to Source Voltage: 100 V; (2)VGS Gate to Source Voltage: ±20 V; (3)EAS Single Pulse Avalanche Energy (Note 1): 393 mJ; (4)PD Power dissipation: 310 W; (5)PD Derate above 25℃: 2.07 W/℃; (6)TJ, TSTG Operating and Storage Temperature: -55 to 175 ℃.
Features
FDP3632 features: (1)rDS(ON)= 7.5mΩ (Typ.), VGS = 10V, ID = 80A; (2)Qg(tot)= 84nC (Typ.), VGS = 10V; (3)Low Miller Charge; (4)Low QRR Body Diode; (5)UIS Capability (Single Pulse and Repetitive Pulse); (6)Qualified to AEC Q101.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() FDP3632 |
![]() Fairchild Semiconductor |
![]() MOSFET 100V 80a .9 Ohms/VGS=1V |
![]() Data Sheet |
![]()
|
|
||||||||||||
![]() |
![]() FDP3632_Q |
![]() Fairchild Semiconductor |
![]() MOSFET 100V 80a .9 Ohms/VGS=1V |
![]() Data Sheet |
![]() Negotiable |
|
