MOC3083

6-Pin, DIP6, Zero-Cross Optoisolator, Zero Voltage Crossing, 120mW, 1 A

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.20~0.25 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.20~0.25

PartNumber:: MOC3083

Brand:: Fairchild Semiconductor - Fairchild | Pack: DIP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. bei's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-11-27

From Other Seller

Part Number:MOC3083
US $0.20 - 0.25
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MOC3083 is a Zero-Cross Optoisolator. The MOC3083 is designed for use with a triac in the interface of logic systems to equipment powered from 240 Vac lines, such as solid–state relays, industrial controls, motors, solenoids and consumer appliances, etc.

Parametrics

MOC3083 maximum ratings: (1)Reverse Voltage VR: 6 Volts; (2)Forward Current — Continuous IF: 60 mA; (3)Total Power Dissipation @ TA = 25℃ Negligible Power in Output Driver: PD 120mW; (4)Derate above 25℃: 1.41 mW/℃; (5)Off–State Output Terminal Voltage VDRM: 800 Volts; (6)Peak Repetitive Surge Current(PW = 100 ms, 120 pps)ITSM: 1 A; (7)Total Power Dissipation @ TA = 25℃ PD: 150mW; (8)Derate above 25℃: 1.76mW/℃.

Features

MOC3083 features: (1)Simplifies Logic Control of 240 Vac Power; (2)Zero Voltage Crossing; (3)dv/dt of 1500 V/μs Typical, 600 V/μs Guaranteed; (4)To order devices that are tested and marked per VDE 0884 requirements, the suffix "V" must be included at end of part number. VDE 0884 is a test option.
