Product Summary
The PT2272-M4 is a remote control decoder paired with PT 2262 ultilizing CMOS Technology. It has 12 bites of tri-state address pins providing a maximum of 531,441 address codes; thereby, drastically reducing any code collision and unauthorized code scanning possibilities. The PT2272-M4 is available in several options to suit every application need: variable number of data output pins, latch or mementary output type. Applications include car security system, garage door controller, remote control fan, home security/ automation system, remote control toys and remote control for industrial use.
Parametrics
PT2272-M4 absolute maximum ratings: (1)Supply Voltage: -0.3 ~ 16.0 V; (2)Input Voltage: -0.3 ~ VCC+0.3 V; (3)Output Voltage: -0.3 ~ VCC+0.3 V; (4)Operating Temperature: -40 ~ +85℃; (5)Storage Temperature: -65 ~ 150℃.
Features
PT2272-M4 features: (1)COMS technology; (2)Low power consumption; (3)very high nosie immunity; (4)Up to 12 tri-state code address pins; (5)Up to 6 data pins; (6)Wide range of operating voltage; (7)Single resistor oscillator; (8)Latch or momentary output type; (9)Available in DIP and SO package.
Diagrams
 |
