MAX3232CSE

transceiver, Maxim Integrated, MAX3232CSE, -0.3V to +6V, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.30~0.40

PartNumber:: MAX3232CSE

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. bei's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-11-08

From Other Seller

Part Number:MAX3232CSE
US $0.30 - 0.40
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
AT45DB161B-TI

US $0.90 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX3232CSE is a Transceiver. It has a proprietary low-dropout transmitter output stage enabling true RS-232 performance from a 3.0V to 5.5V supply with a dual charge pump. The MAX3232CSE requires only four small 0.1µF external charge-pump capacitors. The device is guaranteed to run at data rates of 120kbps while maintaining RS-232 output levels. The applications of the MAX3232CSE are Notebook, Subnotebook, and Palmtop Computers, High-Speed Modems, Battery-Powered Equipment, Hand-Held Equipment, Peripherals, Printers.

Parametrics

MAX3232CSE absolute maximum ratings: (1)VCC:-0.3V to +6V; (2)V+ :-0.3V to +7V; (3)V-:+0.3V to -7V; (4)V+ + V-:+13V; (5)Input Voltages: T_IN, SHDN, EN:-0.3V to +6V, MBAUD:-0.3V to (VCC + 0.3V), R_IN:±25V; (6)Output Voltages: T_OUT:±13.2V, R_OUT:-0.3V to (VCC + 0.3V); (7)Short-Circuit Duration: T_OUT:Continuous; (8)Continuous Power Dissipation:696mW; (9)Operating Temperature Ranges:0℃ to +70℃; (10)Storage Temperature Range:-65℃ to +150℃; (11)Lead Temperature (soldering, 10sec):+300℃.

Features

MAX3232CSE features: (1)Low Supply Current:300μA; (2)Guaranteed Data Rate:120kbps; (3)Meets EIA/TIA-232 Specifications Down to 3.0V; (4)Pin Compatible with Industry-Standard MAX232; (5)Guaranteed Slew Rate:6V/μs .
